products

1920hz P6 Conference Room Display Screen Curved Big Size LED Screen

Basic Information
Place of Origin: China
Brand Name: IKE Visual
Certification: CE,RoHS,FCC
Model Number: Wind 6
Minimum Order Quantity: 5SQM
Price: 800$/㎡
Packaging Details: Flight case,Plywood case
Delivery Time: 21days
Payment Terms: T/T, Western Union
Supply Ability: 500PCS/Month
Detail Information
Color: Full Color Pixel Pitch: P6
Brightness: 1200nits Control System: Novastar
LED Chip: 3 In 1 Smd Waterproof: IP43
Refresh Rate: 1920hz
High Light:

P6 Conference Room Display Screen

,

Curved Conference Room Display Screen

,

1920hz Big Size LED Screen


Product Description

P6 Stage LED Display For Curved Background LED Video Wall Rental LED Display Screen

Overview
Wind 6
Quick Details
Application:
Indoor
Color:
Full color
Waterproof
IP43
Pixel Pitch:
P6.25
LED Type:
2727SMD
LED Chio
3 in1 SMD
Place of Origin:
Guangdong, China
Model Number:
Wind 6
Power Consumption
(Max./Avg.)
450W /㎡ / 150W/㎡
Panel size:
W1200mm*H600mm
Use:
LED Video Wall,BIG Billboard and stage screen
Product name:
Flexible LED display
Brightness:
1200 nits
Media Available:
Datasheet, Photo, EDA/CAD Models
Max. Curve:
Min.Diameter 77cm Concave Or Convex
Scan mode:
1/16S
Pixel density:
25600 px/smq
Control system:
Novastar
Weight:
17.5kg/sqm
Refresh Rate:
1920Hz
Customized:
Accept
Product Description

> the absolute HD LED video display screen, good choice for giant TV, screen monitoring;
> SMD 3 in 1 pixel, black LED, wide viewing angle and better contrast for outstanding image;
> Standard steel close cabinet, strong, firm and flat, prevent distortion during shipping and installing. Make sure the whole screen is flat, seamless, playing good and uniform image;
> Small size cabinet unit, light body. Easy for shipping and installing;
> Low voltage module, easy for maintenance;
> Signal and power cable connectors makes all the cable connection easy, tidy and well-aligned. The whole screen is power safe. Naked installing is ok;
> Smooth, exquisite and vivid image. The display is of 10-bit colors, with 65536 gray scale to play natural and vivid image.
> Many mature controlling solutions are optional. 3G, 4G, WIFI, group cloud controlling are available. Camera, cable TV, the 2nd development docking with other devices and optional. There is always a solution suitable for situation needing;
> Top-Brand Components make sure the reliable quality, MW power supply, MBI driving IC, etc.
> All the PCB is covered by conformal coating. It is water proof & insulated in some extent and helpful for heat dissipation;



Wind Series flexible LED display offers outstanding performance with its real flexibility.

1920hz P6 Conference Room Display Screen Curved Big Size LED Screen 0

The unique design contributes to the horizontal and vertical deformed bending installation, making it possible to achieve “S”shaped, round, concave, convex and curved screen.

1920hz P6 Conference Room Display Screen Curved Big Size LED Screen 1

The special soft PCB board design allows Wind series being ever-changing,no matter if you would want concave shape in a concert now,and cylinder LED display in a supermall tomorrow,even would provide a touring show for a stage 2 days later,it will be easily done by Wind Series .

1920hz P6 Conference Room Display Screen Curved Big Size LED Screen 2

We have CE ROHS FCC.
1920hz P6 Conference Room Display Screen Curved Big Size LED Screen 3
Model No
Wind-3
Wind-4/Wind O-4
Wind-6/Wind O-6
Wind-9/Wind O-9
Wind-12/Wind O-12
Pixel Pitch
P3.125mm
P4.6875 mm
P6.25 mm
P9.375 mm
P12.5mm
Density
102400 Pixels/㎡
45512 Pixels/㎡
25600 Pixels/㎡
11378 Pixels/㎡
6400 Pixels/㎡
Brightness
1200 Nits
1200 Nits/5000 Nits
1200 Nits/5000 Nits
1200 Nits/5000 Nits
1200 Nits/5000 Nits
IP Degree
IP43
IP43/IP65
IP43/IP65
IP43/IP65
IP43/IP65
Panel Size
800mm*400mm
1200mm*600mm
1200mm*600mm
1200mm*600mm
1600mm*800mm
Customized Available
Module Resolution
256 x 128
256 x 128
192 x 96
192 x 96
192 x 96
Weight
17.5kg/㎡
17.9kg/㎡
17.5kg/㎡
17.5kg/㎡
17.2kg/㎡
Scan Mode
1/16 Scan
1/16 Scan
1/8 Scan
1/8 Scan│1/4 Scan
1/8 Scan│1/2 Scan
Max. Power Consumption
800 W /㎡
Indoor: 700 W /㎡
Indoor: 700 W /㎡
Indoor: 300 W /㎡
Indoor: 200 W /㎡
Outdoor:830 W/㎡
Outdoor:830 W/㎡
Outdoor:600 W/㎡
Outdoor:600 W/㎡
Avg. Power Consumption
267 W/㎡
Indoor: 230W /㎡
Indoor: 230 W /㎡
Indoor: 100 W /㎡
Indoor: 80 W /㎡
Outdoor:280W/㎡
Outdoor:280 W/㎡
Outdoor:200 W/㎡
Outdoor:200 W/㎡
Viewing Angle
120 degree
Working Voltage
DC 5V
Input Voltage
AC 100-240V
Thickness
7.0cm (With Electronic Box) 1.3cm(Without Electronic Box)



  • Good after s service

1920hz P6 Conference Room Display Screen Curved Big Size LED Screen 4



Our Services



1.Price depends on the quantity. We can offer you the best competitive price with the same even better quality.

2.Good after sale service: We can response in time if customers have questions about the installation , usage and maintenance ect.

3. Your inquiry will be replied by well-trained and experienced staffs in 24 hours.

4. Top Quality+Reasonable Price+Responsible After Service=Successful & Win

5. Help you design OEM&ODM or any your customized lightings and put into production.

6. Your sales area, ideas of design and all your private information will be well protected
